E-raamat: Interpretive Solutions for Dynamic Structures Through ABAQUS Finite Element Packages [Taylor & Francis e-raamat]

(University Putra Malaysia, Selangor, Malaysia), (University of Sheffield, United Kingdom)
  • Formaat: 280 pages, 13 Tables, black and white; 8 Line drawings, black and white; 407 Halftones, black and white; 415 Illustrations, black and white
  • Ilmumisaeg: 15-Dec-2021
  • Kirjastus: CRC Press
  • ISBN-13: 9781003219491
Teised raamatud teemal:
  • Taylor & Francis e-raamat
  • Hind: 216,96 €*
  • * hind, mis tagab piiramatu üheaegsete kasutajate arvuga ligipääsu piiramatuks ajaks
  • Tavahind: 309,94 €
  • Säästad 30%
Interpretive Solutions for Dynamic Structures Through ABAQUS Finite Element PackagesSuurem pilt
  • Formaat: 280 pages, 13 Tables, black and white; 8 Line drawings, black and white; 407 Halftones, black and white; 415 Illustrations, black and white
  • Ilmumisaeg: 15-Dec-2021
  • Kirjastus: CRC Press
  • ISBN-13: 9781003219491
Teised raamatud teemal:
Taylor & Francis e-raamatudRohkem infot Taylor & Francis e-raamatute kohta
Raamatu kodulehekülg: https://www.taylorfrancis.com/books/9781003219491
ABAQUS software is a general-purpose finite element simulation package mainly used for numerically solving a wide variety of design engineering problems; however, its application to simulate the dynamic structures within the civil engineering domain is highly complicated. Therefore, this book aims to present specific complicated and puzzling challenges encountered in the application of Finite Element Method (FEM) for solving the problems related to Structural Dynamics using ABAQUS software that can fully utilize this method in complex simulation and analysis. Various chapters of this book demonstrate the process for the modeling and analysis of impenetrable problems through simplified step-by-step illustration by presenting screenshots from ABAQUS software in each part/step and showing various graphs.

Highlights:











Focuses on solving problems related to Structural Dynamics using ABAQUS software





Helps to model and analyze the different types of structures under various dynamic and cyclic loads





Discusses the simulation of irregularly-shaped objects comprising several different materials with multipart boundary conditions





Includes the application of various load effects to develop structural models using ABAQUS software





Covers a broad array of applications such as bridges, offshores, dams, and seismic resistant systems

Overall, this book is aimed at graduate students, researchers, and professionals in structural engineering, solid mechanics, and civil engineering.
