Physics and Technology of Crystalline Oxide Semiconductor CAAC-IGZO: Application to LSI [Hardback]

Edited by , Edited by
  • Format: Hardback, 376 pages, height x width x depth: 246x173x23 mm, weight: 726 g
  • Series: Wiley Series in Display Technology
  • Pub. Date: 23-Dec-2016
  • Publisher: John Wiley & Sons Inc
  • ISBN-10: 1119247349
  • ISBN-13: 9781119247340
Other books in subject:
  • Hardback
  • Price: 126,93 €
  • This book is not in stock. Book will arrive in about 2-4 weeks. Please allow another 2 weeks for shipping outside Estonia.
  • Quantity:
  • Add to basket
  • Delivery time 4-6 weeks
  • Add to Wishlist
  • For Libraries
Physics and Technology of Crystalline Oxide Semiconductor CAAC-IGZO: Application to LSILarger Image
  • Format: Hardback, 376 pages, height x width x depth: 246x173x23 mm, weight: 726 g
  • Series: Wiley Series in Display Technology
  • Pub. Date: 23-Dec-2016
  • Publisher: John Wiley & Sons Inc
  • ISBN-10: 1119247349
  • ISBN-13: 9781119247340
Other books in subject:
Permanent link: https://www.kriso.ee/db/9781119247340.html
Keywords:
This book describes the application of c-axis aligned crystalline In-Ga-Zn oxide (CAAC-IGZO) technology in large-scale integration (LSI) circuits. The applications include Non-volatile Oxide Semiconductor Random Access Memory (NOSRAM), Dynamic Oxide Semiconductor Random Access Memory (DOSRAM), central processing unit (CPU), field-programmable gate array (FPGA), image sensors, and etc. The book also covers the device physics (e.g., off-state characteristics) of the CAAC-IGZO field effect transistors (FETs) and process technology for a hybrid structure of CAAC-IGZO and Si FETs. It explains an extremely low off-state current technology utilized in the LSI circuits, demonstrating reduced power consumption in LSI prototypes fabricated by the hybrid process. A further two books in the series will describe the fundamentals; and the specific application of CAAC-IGZO to LCD and OLED displays.

Key features:

• Outlines the physics and characteristics of CAAC-IGZO FETs that contribute to favorable operations of LSI devices.
• Explains the application of CAAC-IGZO to LSI devices, highlighting attributes including low off-state current, low power consumption, and excellent charge retention.
• Describes the NOSRAM, DOSRAM, CPU, FPGA, image sensors, and etc., referring to prototype chips fabricated by a hybrid process of CAAC-IGZO and Si FETs.
