Broadband Opto-Electrical Receivers in Standard CMOS starts from the basic fundamentals necessary for the design of opto-electronic interface circuits. The book continues with an in-depth analysis of the photodiode, transimpedance amplifier (TIA) and limiting amplifier (LA). To thoroughly understand the light detection mechanisms in silicon, first a one-dimensional and second a two-dimensional model is developed. Analytical design equations are derived to guide the design of the amplifying circuits. For the TIA, the focus is on the sensitivity-speed trade-off. For the LA, a high gain-bandwidth is pursued. Several practical design examples reveal the subtleties and challenges encountered during the design of high-performance analog circuits.



Broadband Opto-Electrical Receivers in Standard CMOS covers the total design flow of monolithic CMOS optical receivers. All material is experimentally verified with several CMOS implementations, with ultimately a fully integrated Gbit/s optical receiver front-end including photodiode, TIA and LA.
Preface v
List of Abbreviations and Symbols
vii
Introduction
1(12)
A History of Optical Communication
1(3)
Emerging Applications
4(3)
Silicon Opto-Electronics
7(2)
Outline of the Work
9(4)
Optical Receiver Fundamentals
13(14)
Introduction
13(1)
The Optical Receiver Front-End
13(4)
A Transceiver for Optical Communication Systems
13(2)
A Pickup Unit for Optical Storage Systems
15(2)
Binary Data Formats
17(3)
Bit Error Rate and Sensitivity
20(3)
Bit Error Rate
20(2)
Sensitivity
22(1)
Intersymbol Interference
23(2)
Low-Pass Filtering
23(1)
High-Pass Filtering
24(1)
Jitter
25(1)
Conclusions
26(1)
Standard CMOS Photodiodes
27(34)
Introduction
27(1)
Basic Concepts
27(5)
Principles of Light Detection
28(3)
The Use of Standard CMOS
31(1)
Overview of Published Integrated Photodiodes
32(5)
BiCMOS Implementations
32(2)
SOI Implementations
34(1)
CMOS Implementations
35(1)
Conclusions
36(1)
One-Dimensional Model
37(9)
N-Well P-Substrate Junction
37(6)
P+ N-Well Junction with Guard
43(3)
Two-Dimensional Model
46(12)
Classical N-Well Diode
46(3)
P+ N-Well Diode with Guard
49(2)
Differential N-Well Diode
51(1)
Influence of Wavelength
52(4)
Influence of Technology Scaling
56(2)
Conclusions
58(3)
Transimpedance Amplifier Design
61(46)
Introduction
61(1)
Performance Requirements
61(2)
Design of the Shunt-Shunt Feedback TIA
63(13)
Transimpedance Gain and Bandwidth
64(4)
Open-Loop Gain and Loop Gain
68(2)
Noise
70(6)
Literature Examples
76(5)
Common Source TIA
77(1)
Regulated Cascode TIA
78(2)
The Latest Trends at ISSCC
80(1)
Case Studies
81(22)
An Inverter-Based TIA for Test Photodiodes in 0.18 μm CMOS
82(11)
An Inverter-Based TIA for Test Photodiodes in 90 nm CMOS
93(4)
A Differential Bandwidth-Optimized TIA in 0.18 μm CMOS
97(6)
Conclusions
103(4)
Post-Amplifier Design
107(26)
Introduction
107(1)
Performance Requirements
108(2)
Literature Examples
110(3)
Design of a Fully Differential Broadband LA
113(11)
Cascaded Gain Stages
114(2)
Broadband Cherry-Hooper Stage
116(4)
Broadband Stage with Capacitive Source Degeneration
120(2)
Offset Compensation
122(2)
Case Studies
124(5)
A Four-Stage LA in 0.18 μm CMOS
124(2)
A Five-Stage LA with Offset Compensation in 0.18 μm CMOS
126(3)
Conclusions
129(4)
CMOS Realizations
133(34)
Introduction
133(2)
Test Photodiodes with TIA in 0.18 μm CMOS
135(7)
Circuit Description
135(3)
Measurements
138(4)
Test Photodiodes with TIA in 90 nm CMOS
142(4)
Circuit Description
143(1)
Measurements
144(2)
Gbit/s LA in 0.18 μm CMOS
146(6)
Circuit Description
147(2)
Measurements
149(3)
A Gbit/s Monolithic Optical Receiver Front-End in 0.18 μm CMOS
152(12)
Circuit Description
152(5)
Measurements
157(7)
Conclusions
164(3)
Conclusions
167(4)
References 171(6)
Index 177
