CMOS: Circuit Design, Layout, and Simulation 4th edition [Kõva köide]

4.26/5 (80 hinnangut Goodreads-ist)
(Boise State University, Micron Technology, Inc., Boise, Idaho)
  • Formaat: Hardback, 1280 pages, kõrgus x laius x paksus: 277x221x53 mm, kaal: 2744 g
  • Sari: IEEE Press Series on Microelectronic Systems
  • Ilmumisaeg: 06-Aug-2019
  • Kirjastus: Wiley-IEEE Press
  • ISBN-10: 1119481511
  • ISBN-13: 9781119481515
Teised raamatud teemal:
CMOS: Circuit Design, Layout, and Simulation 4th editionSuurem pilt
  • Formaat: Hardback, 1280 pages, kõrgus x laius x paksus: 277x221x53 mm, kaal: 2744 g
  • Sari: IEEE Press Series on Microelectronic Systems
  • Ilmumisaeg: 06-Aug-2019
  • Kirjastus: Wiley-IEEE Press
  • ISBN-10: 1119481511
  • ISBN-13: 9781119481515
Teised raamatud teemal:
Püsilink: https://www.kriso.ee/db/9781119481515.html
Märksõnad:

A revised guide to the theory and implementation of CMOS analog and digital IC design

The fourth edition of CMOS: Circuit Design, Layout, and Simulation is an updated guide to the practical design of both analog and digital integrated circuits. The author—a noted expert on the topic—offers a contemporary review of a wide range of analog/digital circuit blocks including: phase-locked-loops, delta-sigma sensing circuits, voltage/current references, op-amps, the design of data converters, and switching power supplies.

CMOS includes discussions that detail the trade-offs and considerations when designing at the transistor-level. The companion website contains numerous examples for many computer-aided design (CAD) tools. Using the website enables readers to recreate, modify, or simulate the design examples presented throughout the book. In addition, the author includes hundreds of end-of-chapter problems to enhance understanding of the content presented. This newly revised edition:

•    Provides in-depth coverage of both analog and digital transistor-level design techniques

•    Discusses the design of phase- and delay-locked loops, mixed-signal circuits, data converters, and circuit noise

•    Explores real-world process parameters, design rules, and layout examples

•    Contains a new chapter on Power Electronics

Written for students in electrical and computer engineering and professionals in the field, the fourth edition of CMOS: Circuit Design, Layout, and Simulation is a practical guide to understanding analog and digital transistor-level design theory and techniques.
