Electrical Installation Design Guide: Calculations for Electricians and Designers 3rd edition [Pehme köide]

5.00/5 (2 hinnangut Goodreads-ist)
  • Formaat: Paperback / softback, 208 pages, kõrgus x laius: 297x210 mm
  • Sari: Electrical Regulations
  • Ilmumisaeg: 11-Apr-2016
  • Kirjastus: Institution of Engineering and Technology
  • ISBN-10: 1849198853
  • ISBN-13: 9781849198851
Teised raamatud teemal:
Electrical Installation Design Guide: Calculations for Electricians and Designers 3rd editionSuurem pilt
  • Formaat: Paperback / softback, 208 pages, kõrgus x laius: 297x210 mm
  • Sari: Electrical Regulations
  • Ilmumisaeg: 11-Apr-2016
  • Kirjastus: Institution of Engineering and Technology
  • ISBN-10: 1849198853
  • ISBN-13: 9781849198851
Teised raamatud teemal:
Püsilink: https://www.kriso.ee/db/9781849198851.html
The book provides step-by-step guidance on the design of electrical installations, from domestic installation final circuit design to fault level calculations for LV systems.



Updated to include the new requirements in Amendment 3 to BS 7671:2008, the Electrical Installation Design Guide reflects important changes to:







Definitions throughout the Regulations Earth fault loop impedances for all protective devices



Amendment 3 published on 5 January 2015 and comes into effect on 1 July 2015. All new installations from this point must comply with Amendment 3 to BS 7671:2008.
Cooperating organisations 6(1)
Preface 7(2)
Chapter 1 Design sequence
9(4)
1.1 Load characteristics
9(1)
1.2 Supply characteristics
10(1)
1.3 Installation outline
10(1)
1.4 Distribution design
10(1)
1.5 Standard final circuits
11(1)
1.6 Isolation and switching
11(1)
1.7 Final assessment
11(1)
1.8 Compliance with BS 7671
11(2)
Chapter 2 Simple installations and final circuits
13(14)
2.1 Introduction
13(1)
2.2 Supply characteristics
13(3)
2.3 Fault rating of switchgear
16(1)
2.4 Final circuit overcurrent protective devices and cables
16(5)
2.5 Final circuit voltage drop limitations
21(2)
2.6 Fault protection
23(2)
2.7 Short-circuit current protection
25(1)
2.8 Protective conductors
25(1)
2.9 Standard final circuits
26(1)
Chapter 3 Maximum demand and diversity
27(16)
3.1 Introduction
27(2)
3.2 Installation outline
29(1)
3.3 Final circuit current demand
30(2)
3.4 Diversity between final circuits
32(4)
3.5 Complex installations
36(7)
Chapter 4 Selection of cables for current-carrying capacity
43(20)
4.0 Symbols
43(1)
4.1 Preliminary design
43(1)
4.2 Overcurrent requirements
44(2)
4.3 Current-carrying capacity tables
46(9)
4.4 Protection against overload and short-circuit
55(1)
4.5 Protection against fault current only (omission of overload protection)
56(2)
4.6 Corrections for grouping not liable to simultaneous overload
58(1)
4.7 Motors
59(4)
Chapter 5 Voltage drop
63(8)
5.1 Voltage drop in consumers' installations
63(1)
5.2 Distribution system voltage drop
63(1)
5.3 Basic voltage drop calculation
64(2)
5.4 Correction for inductance
66(2)
5.5 Correction for load power factor
68(1)
5.6 Correction for conductor operating temperature
69(1)
5.7 Correction for both conductor operating temperature and load power factor
70(1)
Chapter 6 Calculation of fault current
71(12)
6.1 Determination of prospective fault current
71(2)
6.2 Determined by enquiry
73(3)
6.3 Determined by calculation
76(7)
Chapter 7 Shock protection
83(8)
7.1 Shock protection
83(1)
7.2 Protective measure: automatic disconnection of supply
84(4)
7.3 Circuit calculations
88(3)
Chapter 8 Protection against fault current
91(26)
8.1 The adiabatic equation
91(2)
8.2 Selection from Table 54.7
93(2)
8.3 Introduction to calculations
95(1)
8.4 Simple calculation
95(3)
8.5 Energy let-through calculation
98(3)
8.6 Plotting protective conductor adiabatics
101(4)
8.7 Protective conductor as a sheath or armour of a cable
105(1)
8.8 Plotting of cable armour adiabatics
106(1)
8.9 Calculation of armour capability
107(3)
8.10 Conduit and trunking
110(1)
8.11 Earthing and bonding conductors
111(6)
Chapter 9 Calculations associated with testing
117(6)
9.1 General
117(1)
9.2 Continuity
118(1)
9.3 Earth fault loop impedance Zs
118(3)
9.4 Reduced section protective conductors
121(2)
Chapter 10 Impedance of copper and aluminium conductors
123(6)
10.1 Introduction
123(1)
10.2 Conductor resistance and temperature
123(1)
10.3 Impedance of cables from voltage drop tables
124(5)
Chapter 11 Harmonics
129(6)
11.1 Introduction
129(1)
11.2 Cable ratings
130(1)
11.3 Voltage drop
131(2)
11.4 Overcurrent protection
133(2)
Chapter 12 Protection against voltage disturbances
135(6)
12.1 Introduction
135(1)
12.2 The overvoltages
135(1)
12.3 Power frequency fault voltages
135(4)
12.4 Power frequency stress voltages
139(1)
12.5 Earthing of 11 kV substations
139(2)
Chapter 13 Busbar trunking
141(4)
13.1 Symbols
141(1)
13.2 Voltage drop
141(1)
13.3 Fault currents
142(3)
Appendix A Symbols
145(4)
Appendix B Standard final circuits
149(16)
Appendix C Avoidance of unintentional operation of circuit-breakers
165(4)
C.1 Lighting circuit applications
166(3)
Appendix D Further cable calculations
169(6)
D.1 Cable life
169(1)
D.2 Temperatures (core and sheath) (Effect of load current on conductor operating temperature)
170(1)
D.3 Inductance of cables in parallel
170(1)
D.4 Calculation of sheath voltages
171(4)
Appendix E Symbols from CENELEC report CLC/TR 50480
175(2)
Appendix F Equipment data
177(22)
Index 199
