Fault Tolerant Attitude Estimation for Small Satellites [Kõva köide]

, (Istanbul Technical University, Aeronautical Engineering Dept.)
  • Formaat: Hardback, 330 pages, kõrgus x laius: 234x156 mm, kaal: 834 g, 18 Tables, black and white; 10 Illustrations, color; 135 Illustrations, black and white
  • Ilmumisaeg: 23-Dec-2020
  • Kirjastus: CRC Press Inc
  • ISBN-10: 0815369816
  • ISBN-13: 9780815369813
Teised raamatud teemal:
Fault Tolerant Attitude Estimation for Small SatellitesSuurem pilt
  • Formaat: Hardback, 330 pages, kõrgus x laius: 234x156 mm, kaal: 834 g, 18 Tables, black and white; 10 Illustrations, color; 135 Illustrations, black and white
  • Ilmumisaeg: 23-Dec-2020
  • Kirjastus: CRC Press Inc
  • ISBN-10: 0815369816
  • ISBN-13: 9780815369813
Teised raamatud teemal:
Püsilink: https://www.kriso.ee/db/9780815369813.html
Märksõnad:
Small satellites use commercial off-the-shelf sensors and actuators for attitude determination and control (ADC) to reduce the cost. These sensors and actuators are usually not as robust as the available, more expensive, space-proven equipment. As a result, the ADC system of small satellites is more vulnerable to any fault compared to a system for larger competitors. This book aims to present useful solutions for fault tolerance in ADC systems of small satellites. The contents of the book can be divided into two categories: fault tolerant attitude filtering algorithms for small satellites and sensor calibration methods to compensate the sensor errors. MATLAB® will be used to demonstrate simulations.











Presents fault tolerant attitude estimation algorithms for small satellites with an emphasis on algorithms practicability and applicability





Incorporates fundamental knowledge about the attitude determination methods at large





Discusses comprehensive information about attitude sensors for small satellites





Reviews calibration algorithms for small satellite magnetometers with simulated examples





Supports theory with MATLAB simulation results which can be easily understood by individuals without a comprehensive background in this field





Covers up-to-date discussions for small satellite attitude systems design

Dr. Chingiz Hajiyev is a professor at the Faculty of Aeronautics and Astronautics, Istanbul Technical University (Istanbul, Turkey).

Dr. Halil Ersin Soken is an assistant professor at the Aerospace Engineering Department, Middle East Technical University (Ankara, Turkey).
