Finite Element Mesh Generation [Kõva köide]

4.00/5 (4 hinnangut Goodreads-ist)
(University of Hong Kong)
  • Formaat: Hardback, 672 pages, kõrgus x laius: 254x178 mm, kaal: 1460 g, 64 Tables, black and white; 607 Illustrations, black and white
  • Ilmumisaeg: 15-Jan-2015
  • Kirjastus: CRC Press
  • ISBN-10: 041569048X
  • ISBN-13: 9780415690485
Teised raamatud teemal:
Finite Element Mesh GenerationSuurem pilt
  • Formaat: Hardback, 672 pages, kõrgus x laius: 254x178 mm, kaal: 1460 g, 64 Tables, black and white; 607 Illustrations, black and white
  • Ilmumisaeg: 15-Jan-2015
  • Kirjastus: CRC Press
  • ISBN-10: 041569048X
  • ISBN-13: 9780415690485
Teised raamatud teemal:
Püsilink: https://www.kriso.ee/db/9780415690485.html
Märksõnad:
Preface Nowadays, the finite element method has diverse applications to problems in science and engineering ranging from simple two-dimensional static elasticity, non-linear large deformation analysis to three-dimensional fluid dynamic problems with shock waves. The prerequisite for a finite element analysis is a sound and valid finite element mesh, which can only be constructed efficiently by means of some well-devised and thoroughly tested computer algorithms. In contrast to the numerous textbooks, monographs, journal papers, etc., on the finite element method, comprehensive and concise accounts on mesh generation technologies seem to have been missing, except perhaps the book Mesh Generation: Application to Finite Elements written by P.J. Frey and P.L. George some 15 years ago. Anyway, finite element mesh generation has not been taken as a formal subject of teaching in universities, as it encompasses several disciplines including classical geometry, computational geometry and topology, finite elementmethod, data structures and algorithms, computer programming and, to a certain extent, even computer graphics. With the ever-improving performance of PCs, large-scale challenging engineering simulations and scientific computations by means of the finite element method are more accessible to daily design operations and even to research students. In line with this development, the mesh generation methodology is becoming increasingly recognised as a subject in its own right. As meshing technologies and their applications in new areas have developed pretty rapidly over the recent years, it is imperative to review and consolidate the progress in meshing technologies achieved thus far into a concise yet comprehensive text with a logical-- Highlights the Progression of Meshing Technologies and Their ApplicationsFinite Element Mesh Generation provides a concise and comprehensive guide to the application of finite element mesh generation over 2D domains, curved surfaces, and 3D space. Organised according to the geometry and dimension of the problem domains, it develops from the basic meshing algorithms to the most advanced schemes to deal with problems with specific requirements such as boundary conformity, adaptive and anisotropic elements, shape qualities, and mesh optimization.It sets out the fundamentals of popular techniques, including:Delaunay triangulationAdvancing-front (ADF) approachQuadtree/Octree techniquesRefinement and optimization-based strategiesFrom the geometrical and the topological aspects and their associated operations and inter-relationships, each approach is vividly described and illustrated with examples. Beyond the algorithms, the book also explores the practice of using metric tensor and surface curvatures for generating anisotropic meshes on parametric space. It presents results from research including 3D anisotropic meshing, mesh generation over unbounded domains, meshing by means of intersection, re-meshing by Delaunay-ADF approach, mesh refinement and optimization, generation of hexahedral meshes, and large scale and parallel meshing, along with innovative unpublished meshing methods. The author provides illustrations of major meshing algorithms, pseudo codes, and programming codes in C++ or FORTRAN.Geared toward research centers, universities, and engineering companies, Finite Element Mesh Generation describes mesh generation methods and fundamental techniques, and also serves as a valuable reference for laymen and experts alike.

Arvustused

" the present monograph fills a gaping hole in the literature on scientific computing it could be subtitled by 'All you want to know about mesh generation'." Zentralblatt MATH, 2015

"This book provides a well-structured and thorough treatment of very recent research on mesh generation, in a single well organized document. The descriptions of methods and algorithms are complete and provide readers with all the necessary information needed to implement on their own the algorithms and methods discussed in the book. Numerical examples provide concrete measures of the performance of the algorithms and can serve as a reference for those interested in validating their own implementations."

Francois Guibault, Polytechnique Montreal, Canada

"there are very few books on this subject. Daniel Los book (examining the contents) offers a practical point of view and gives details on some topics which, I think, are not cover[ ed] by the other books on meshing techniques." Houman Borouchaki, Université de Technologie de Troyes, France

"This book brings together the major propulsion system components with control oriented models and actuators to enable software and hardware-in-the-loop simulations. This book will provide students with a detailed set of component models and simulation tools to learn Rapid Control Prototyping methods." Douglas J. Nelson, Professor of Mechanical Engineering, Virginia Tech

"This book is aimed at those who want a comprehensive overview of the techniques of finite-element mesh generation. The techniques and algorithms are clearly explained and there are good references to follow up where greater detail is required. However, there is probably a broader readership among practising engineers, who use the finite-element method on a daily basis, and who want a better understanding of the tools they rely on as a basis for their calculations."

Stephen Hendry, Engineering and Computational Mechanics " the present monograph fills a gaping hole in the literature on scientific computing it could be subtitled by 'All you want to know about mesh generation'." Zentralblatt MATH, 2015

"This book provides a well-structured and thorough treatment of very recent research on mesh generation, in a single well organized document. The descriptions of methods and algorithms are complete and provide readers with all the necessary information needed to implement on their own the algorithms and methods discussed in the book. Numerical examples provide concrete measures of the performance of the algorithms and can serve as a reference for those interested in validating their own implementations."

Francois Guibault, Polytechnique Montreal, Canada

"there are very few books on this subject. Daniel Los book (examining the contents) offers a practical point of view and gives details on some topics which, I think, are not cover[ ed] by the other books on meshing techniques." Houman Borouchaki, Université de Technologie de Troyes, France

"This book brings together the major propulsion system components with control oriented models and actuators to enable software and hardware-in-the-loop simulations. This book will provide students with a detailed set of component models and simulation tools to learn Rapid Control Prototyping methods." Douglas J. Nelson, Professor of Mechanical Engineering, Virginia Tech

"This book is aimed at those who want a comprehensive overview of the techniques of finite-element mesh generation. The techniques and algorithms are clearly explained and there are good references to follow up where greater detail is required. However, there is probably a broader readership among practising engineers, who use the finite-element method on a daily basis, and who want a better understanding of the tools they rely on as a basis for their calculations."

Stephen Hendry, Engineering and Computational Mechanics
