Microchip Fabrication: A Practical Guide to Semiconductor Processing, Sixth Edition 6th edition [Kõva köide]

3.87/5 (24 hinnangut Goodreads-ist)

Peter Van Zant

Formaat: Hardback, 576 pages, kõrgus x laius x paksus: 241x196x37 mm, kaal: 1136 g, 225 Illustrations
Ilmumisaeg: 16-Nov-2013
Kirjastus: McGraw-Hill Professional
ISBN-10: 0071821015
ISBN-13: 9780071821018

Teised raamatud teemal:

Microprocessors

Kõva köide
Hind: 202,59 €
Raamatu kohalejõudmiseks kirjastusest kulub orienteeruvalt 2-4 nädalat
Kogus:
- - 1
  - 2
  - 3
  - 4
  - 5
  - 6
  - 7
  - 8
  - 9
  - 10
Lisa ostukorvi
Tasuta tarne
Tellimisaeg 2-4 nädalat
Lisa soovinimekirja

Formaat: Hardback, 576 pages, kõrgus x laius x paksus: 241x196x37 mm, kaal: 1136 g, 225 Illustrations
Ilmumisaeg: 16-Nov-2013
Kirjastus: McGraw-Hill Professional
ISBN-10: 0071821015
ISBN-13: 9780071821018

Teised raamatud teemal:

Microprocessors

Püsilink: https://www.kriso.ee/db/9780071821018.html

Märksõnad:

Van Zant updates and revises his introductory textbook for semiconductor wafer-fabrication workers whether they be production workers, technicians, professionals in the materials and equipment sectors, or engineers. In this edition he retains the fundamental physics, chemistry, and electronics underlying the sophisticated manufacturing materials and process of modern semiconductor fabrication, and integrates the current processes. Among the topics are crystal growth and silicon wafer preparation, productivity and process yields, next generation lithography, evaluating processes and devices, and packaging. Annotation ©2014 Ringgold, Inc., Portland, OR (protoview.com)

The most complete, current guide to semiconductor processing

Fully revised to cover the latest advances in the field, Microchip Fabrication, Sixth Editionexplains every stage of semiconductor processing, from raw material preparation to testing to packaging and shipping the finished device. This practical resource provides easy-to-understand information on the physics, chemistry, and electronic fundamentals underlying the sophisticated manufacturing materials and processes of modern semiconductors.

State-of-the-art processes and cutting-edge technologies used in the patterning, doping, and layering steps are discussed in this new edition. Filled with detailed illustrations and real-world examples, this is a comprehensive, up-to-date introduction to the technologicalbackbone of the high-tech industry.

COVERAGE INCLUDES:

The semiconductor industry
Properties of semiconductor materials and chemicals
Crystal growth and silicon wafer preparation
Wafer fabrication and packaging
Contamination control
Productivity and process yields
Oxidation
The ten-step patterning process--surface preparation to exposure; developing to final inspection
Next generation lithography
Doping
Layer deposition
Metallization
Process and device evaluation
The business of wafer fabrication
Devices and integrated circuit formation
Integrated circuits
Packaging
