Microelectronic Circuit Design 4th edition [Kõva köide]

3.70/5 (36 hinnangut Goodreads-ist)
,
  • Formaat: Hardback, 1376 pages, kõrgus x laius x paksus: 262x203x48 mm, kaal: 2542 g, Illustrations
  • Ilmumisaeg: 16-Mar-2010
  • Kirjastus: McGraw-Hill Professional
  • ISBN-10: 0073380458
  • ISBN-13: 9780073380452
Teised raamatud teemal:
  • Kõva köide
  • Hind: 236,79 €*
  • * saadame teile pakkumise kasutatud raamatule, mille hind võib erineda kodulehel olevast hinnast
  • See raamat on trükist otsas, kuid me saadame teile pakkumise kasutatud raamatule.
  • Kogus:
  • Lisa ostukorvi
  • Tasuta tarne
  • Lisa soovinimekirja
Microelectronic Circuit Design 4th editionSuurem pilt
  • Formaat: Hardback, 1376 pages, kõrgus x laius x paksus: 262x203x48 mm, kaal: 2542 g, Illustrations
  • Ilmumisaeg: 16-Mar-2010
  • Kirjastus: McGraw-Hill Professional
  • ISBN-10: 0073380458
  • ISBN-13: 9780073380452
Teised raamatud teemal:
Püsilink: https://www.kriso.ee/db/9780073380452.html
Märksõnad:

Richard Jaeger and Travis Blalock present a balanced coverage of analog and digital circuits; students will develop a comprehensive understanding of the basic techniques of modern electronic circuit design, analog and digital, discrete and integrated.

A broad spectrum of topics are included in Microelectronic Circuit Design which gives the professor the option to easily select and customize the material to satisfy a two-semester or three-quarter sequence in electronics. Jaeger/Blalock emphasizes design through the use of design examples and design notes. Excellent pedagogical elements include chapter opening vignettes, chapter objectives, “Electronics in Action” boxes, a problem-solving methodology, and "Design Note” boxes.

The use of the well-defined problem-solving methodology presented in this text can significantly enhance an engineer’s ability to understand the issues related to design. The design examples assist in building and understanding the design process.
