Operational Amplifiers 2nd ed. 2011 [Kõva köide]

Johan H. Huijsing

Teised formaadid

Pehme köide (Hind: 215,88 €) - 07-Dec-2010

Formaat: Hardback, 433 pages, kõrgus x laius x paksus: 234x156x23 mm, kaal: 785 g, biography, Contains 1 Book and 1 Digital online
Ilmumisaeg: 28-Apr-2011
Kirjastus: Springer
ISBN-10: 9400705956
ISBN-13: 9789400705951

Teised raamatud teemal:

Circuits & components - (Hetkel poes: 1 nimetust)

Kõva köide
Hind: 94,98 €*
* hind on lõplik, st. muud allahindlused enam ei rakendu
Tavahind: 111,75 €
Säästad 15%
Raamatu kohalejõudmiseks kirjastusest kulub orienteeruvalt 2-4 nädalat
Kogus:
- - 1
  - 2
  - 3
  - 4
  - 5
  - 6
  - 7
  - 8
  - 9
  - 10
Lisa ostukorvi
Tasuta tarne
Tellimisaeg 2-4 nädalat
Lisa soovinimekirja

Formaat: Hardback, 433 pages, kõrgus x laius x paksus: 234x156x23 mm, kaal: 785 g, biography, Contains 1 Book and 1 Digital online
Ilmumisaeg: 28-Apr-2011
Kirjastus: Springer
ISBN-10: 9400705956
ISBN-13: 9789400705951

Teised raamatud teemal:

Circuits & components - (Hetkel poes: 1 nimetust)

Püsilink: https://www.kriso.ee/db/9789400705951.html

Märksõnad:

Operational Amplifiers - Theory and Design, Second Edition presents a systematic circuit design of operational amplifiers. Containing state-of-the-art material as well as the essentials, the book is written to appeal to both the circuit designer and the system designer. It is shown that the topology of all operational amplifiers can be divided into nine main overall configurations. These configurations range from one gain stage up to four or more stages. Many famous designs are evaluated in depth.Additional chapters included are on systematic design of µV-offset operational amplifiers and precision instrumentation amplifiers by applying chopping, auto-zeroing, and dynamic element-matching techniques. Also, techniques for frequency compensation of amplifiers with high capacitive loads have been added.Operational Amplifiers - Theory and Design, Second Edition presents high-frequency compensation techniques to HF-stabilize all nine configurations. Special emphasis is placed on low-power low-voltage architectures with rail-to-rail input and output ranges.In addition to presenting characterization of operational amplifiers by macro models and error matrices, together with measurement techniques for their parameters it also develops the design of fully differential operational amplifiers and operational floating amplifiers.Operational Amplifiers - Theory and Design, Second Edition is carefully structured and enriched by numerous figures, problems and simulation exercises and is ideal for the purpose of self-study and self-evaluation.

This new edition contains state-of-the-art material as well as the essentials. It includes a systematic approach to the design of chopper and auto-zero OpAmps and Instrumentation Amplifiers with input offset voltages of the order of 1uV.
