Power Systems Analysis Illustrated with MATLAB and ETAP [Kõva köide]

(University of Hartford, Connecticut, USA)
  • Formaat: Hardback, 282 pages, kõrgus x laius: 254x178 mm, kaal: 740 g, 199 Illustrations, black and white
  • Ilmumisaeg: 29-Jan-2019
  • Kirjastus: CRC Press Inc
  • ISBN-10: 1498797210
  • ISBN-13: 9781498797214
Teised raamatud teemal:
Power Systems Analysis Illustrated with MATLAB and ETAPSuurem pilt
  • Formaat: Hardback, 282 pages, kõrgus x laius: 254x178 mm, kaal: 740 g, 199 Illustrations, black and white
  • Ilmumisaeg: 29-Jan-2019
  • Kirjastus: CRC Press Inc
  • ISBN-10: 1498797210
  • ISBN-13: 9781498797214
Teised raamatud teemal:
Püsilink: https://www.kriso.ee/db/9781498797214.html
Märksõnad:
Electrical power is harnessed using several energy sources, including coal, hydel, nuclear, solar, and wind. Generated power is needed to be transferred over long distances to support load requirements of customers, viz., residential, industrial, and commercial. This necessitates proper design and analysis of power systems to efficiently control the power flow from one point to the other without delay, disturbance, or interference. Ideal for utility and power system design professionals and students, this book is richly illustrated with MATLAB® and Electrical Transient Analysis Program (ETAP®) to succinctly illustrate concepts throughout, and includes examples, case studies, and problems.

Features











Illustrated throughout with MATLAB and ETAP





Proper use of positive/negative/zero sequence analysis of a given one-line diagram (OLD) associated with a grid, as well as finger-holding instructions to tackle a power system analysis (PSA) problem for a given OLD of a grid





On-line evaluation of power flow, short-circuit analysis, and related PSA for a given OLD





Appropriately learn the finer nuances of designing the several components of a PSA, including transmission lines, transformers, generators/motors, and illustrate the corresponding equivalent circuit





Case studies from utilities and independent system operators
