ReRAM-based Machine Learning [Kõva köide]

(Huawei Technologies, Shenzhen, China), (George Mason University (GMU), Department of Electrical and Computer Engineering, USA), (Southern University of Science and Technology (SUSTech), School of Microelectronics, China)
  • Formaat: Hardback, 261 pages, kõrgus x laius: 234x156 mm
  • Sari: Computing and Networks
  • Ilmumisaeg: 30-Apr-2021
  • Kirjastus: Institution of Engineering and Technology
  • ISBN-10: 1839530812
  • ISBN-13: 9781839530814
Teised raamatud teemal:
ReRAM-based Machine LearningSuurem pilt
  • Formaat: Hardback, 261 pages, kõrgus x laius: 234x156 mm
  • Sari: Computing and Networks
  • Ilmumisaeg: 30-Apr-2021
  • Kirjastus: Institution of Engineering and Technology
  • ISBN-10: 1839530812
  • ISBN-13: 9781839530814
Teised raamatud teemal:
Püsilink: https://www.kriso.ee/db/9781839530814.html
Märksõnad:

The transition towards exascale computing has resulted in major transformations in computing paradigms. The need to analyze and respond to such large amounts of data sets has led to the adoption of machine learning (ML) and deep learning (DL) methods in a wide range of applications.

One of the major challenges is the fetching of data from computing memory and writing it back without experiencing a memory-wall bottleneck. To address such concerns, in-memory computing (IMC) and supporting frameworks have been introduced. In-memory computing methods have ultra-low power and high-density embedded storage. Resistive Random-Access Memory (ReRAM) technology seems the most promising IMC solution due to its minimized leakage power, reduced power consumption and smaller hardware footprint, as well as its compatibility with CMOS technology, which is widely used in industry.

In this book, the authors introduce ReRAM techniques for performing distributed computing using IMC accelerators, present ReRAM-based IMC architectures that can perform computations of ML and data-intensive applications, as well as strategies to map ML designs onto hardware accelerators.

The book serves as a bridge between researchers in the computing domain (algorithm designers for ML and DL) and computing hardware designers.



Serving as a bridge between researchers in the computing domain and computing hardware designers, this book presents ReRAM techniques for distributed computing using IMC accelerators, ReRAM-based IMC architectures for machine learning (ML) and data-intensive applications, and strategies to map ML designs onto hardware accelerators.
