Thin Film Transistor Circuits and Systems [Kõva köide]

(University of Cambridge),
  • Formaat: Hardback, 184 pages, kõrgus x laius x paksus: 235x155x13 mm, kaal: 420 g, Worked examples or Exercises; 11 Tables, black and white; 113 Line drawings, unspecified
  • Ilmumisaeg: 29-Aug-2013
  • Kirjastus: Cambridge University Press
  • ISBN-10: 1107012333
  • ISBN-13: 9781107012332
Teised raamatud teemal:
Thin Film Transistor Circuits and SystemsSuurem pilt
  • Formaat: Hardback, 184 pages, kõrgus x laius x paksus: 235x155x13 mm, kaal: 420 g, Worked examples or Exercises; 11 Tables, black and white; 113 Line drawings, unspecified
  • Ilmumisaeg: 29-Aug-2013
  • Kirjastus: Cambridge University Press
  • ISBN-10: 1107012333
  • ISBN-13: 9781107012332
Teised raamatud teemal:
Püsilink: https://www.kriso.ee/db/9781107012332.html
Märksõnad:
This book provides a comprehensive review of the design challenges associated with building circuits and systems from thin-film transistors, including architecture, fabrication and design considerations.

Providing a reliable and consolidated treatment of the principles behind large-area electronics, this book provides a comprehensive review of the design challenges associated with building circuits and systems from thin-film transistors. The authors describe the architecture, fabrication and design considerations for the principal types of TFT and their numerous applications. The practicalities of device non-ideality are also addressed and the specific design considerations necessitated by instabilities and non-uniformities in existing fabrication technologies. Containing device-circuit information, discussion of electronic solutions that compensate for material deficiencies, and design methodologies applicable to a wide variety of organic and inorganic disordered materials, this is an essential reference for all researchers, circuit and device engineers working on large-area electronics.

Muu info

A comprehensive review of the design challenges associated with building thin-film transistor circuits and systems and how to overcome them.
Preface viii
1 Introduction 1(12)
1.1 Organic light emitting diode displays
1(5)
1.2 Flat-panel biomedical imagers
6(2)
1.3 Backplane technologies
8(3)
1.4 Organization
11(2)
2 Design considerations 13(33)
2.1 Temporal and spatial non-uniformity
13(2)
2.2 Compensation schemes
15(20)
2.2.1 Current driving scheme
17(8)
2.2.2 Voltage driving scheme
25(10)
2.3 Design considerations for AMOLED displays
35(4)
2.3.1 Lifetime and yield
36(1)
2.3.2 Differential aging and mura
37(1)
2.3.3 Power consumption
38(1)
2.3.4 Aperture ratio
38(1)
2.3.5 IR drop and ground bouncing
38(1)
2.3.6 Implementation cost
39(1)
2.4 Design considerations for flat-panel imager
39(5)
2.4.1 Input referred noise and dynamic range
42(2)
2.4.2 Implementation cost
44(1)
2.5 Summary
44(2)
3 Hybrid voltage-current programming 46(28)
3.1 Multi-modal biomedical imaging pixel circuit
46(6)
3.2 Multi-modal biomedical sensor array
52(14)
3.2.1 Peripheral circuitries
55(2)
3.2.2 Measurement results
57(6)
3.2.3 Improved dynamic range
63(1)
3.2.4 Noise analysis of CBVP pixel circuit
64(2)
3.3 CBVP AMOLED pixel circuit
66(6)
3.4 Summary
72(2)
4 Enhanced-settling current programming 74(19)
4.1 Localized current source
74(3)
4.2 Current feedback
77(1)
4.3 Positive feedback
78(14)
4.3.1 Stability and noise analysis
81(3)
4.3.2 Measurement results and discussion
84(3)
4.3.3 Self-calibration of the current source
87(5)
4.4 Summary
92(1)
5 Charge-based driving scheme 93(21)
5.1 Charge-based pixel circuit
93(10)
5.1.1 Measurement results
95(3)
5.1.2 Implementation of the relaxation technique
98(2)
5.1.3 AMOLED display
100(3)
5.2 Real-time biomedical imaging pixel circuit
103(9)
5.2.1 Noise analysis of charge-based pixel circuit
109(3)
5.3 Summary
112(2)
6 High-resolution architectures 114(24)
6.1 Time-dependent charge injection and clock feed-through
114(6)
6.2 Successive calibration
120(6)
6.3 Arrays structure and timing
126(3)
6.3.1 Blanking-time extraction
128(1)
6.3.2 Simultaneous extraction
128(1)
6.4 Configurable current comparator
129(2)
6.5 Measurement results and discussions
131(5)
6.6 Hybrid approach
136(1)
6.7 Summary
137(1)
7 Summary and outlook 138(4)
Appendix A Enhanced voltage driving schemes 142(9)
A.1 Interleaved addressing scheme
142(9)
A.1.1 3-TFT pixel circuit
143(8)
Appendix B OLED electrical calibration 151(6)
B.1 Interdependence between electrical and luminance degradation
151(1)
B.2 Electrical compensation of OLED degradation
152(2)
B.3 Compensating for different stress levels
154(3)
References 157(10)
Index 167
Reza Chaji is the Chief Technology Officer at Ignis Innovation Inc., managing programmes for the development of low-cost, high-yield and low-power AMOLED displays. He is an Adjunct Professor at the University of Waterloo, Canada and has been awarded the CMC Douglas R. Colton Medal for Research Excellence. Arokia Nathan is the Chair of Photonic Systems and Displays at the University of Cambridge, former Sumitomo Chair of Nanotechnology at the London Centre for Nanotechnology, University College London and the Canada Research Chair, University of Waterloo. The founder or co-founder of several companies, he is also a Fellow of the IEEE and the IET and an IEEE/EDS Distinguished Lecturer.
