Analog-to-Digital Conversion 2nd ed. 2013 [Kõva köide]

  • Formaat: Hardback, 566 pages, kõrgus x laius: 235x155 mm, kaal: 1063 g, 256 black & white illustrations, 206 colour illustrations, 63 black & white tables, biography
  • Ilmumisaeg: 11-Dec-2012
  • Kirjastus: Springer-Verlag New York Inc.
  • ISBN-10: 1461413702
  • ISBN-13: 9781461413707
Teised raamatud teemal:
  • Kõva köide
  • Hind: 119,35 €*
  • * saadame teile pakkumise kasutatud raamatule, mille hind võib erineda kodulehel olevast hinnast
  • See raamat on trükist otsas, kuid me saadame teile pakkumise kasutatud raamatule.
  • Kogus:
  • Lisa ostukorvi
  • Tasuta tarne
  • Lisa soovinimekirja
  • Formaat: Hardback, 566 pages, kõrgus x laius: 235x155 mm, kaal: 1063 g, 256 black & white illustrations, 206 colour illustrations, 63 black & white tables, biography
  • Ilmumisaeg: 11-Dec-2012
  • Kirjastus: Springer-Verlag New York Inc.
  • ISBN-10: 1461413702
  • ISBN-13: 9781461413707
Teised raamatud teemal:
With more than twice the number of exercises than the first edition, this revised and expanded textbook covers the key developments in analog-to-digital conversion in a pedagogical framework suited for both graduate-level courses and professionals.

This textbook is appropriate for use in graduate-level curricula in analog to digital conversion, as well as for practicing engineers in need of a state-of-the-art reference on data converters. It discusses various analog-to-digital conversion principles, including sampling, quantization, reference generation, nyquist architectures and sigma-delta modulation. This book presents an overview of the state-of-the-art in this field and focuses on issues of optimizing accuracy and speed, while reducing the power level. This new, second edition emphasizes novel calibration concepts, the specific requirements of new systems, the consequences of 22-nm technology and the need for a more statistical approach to accuracy. Pedagogical enhancements to this edition include more than twice the exercises available in the first edition, solved examples to introduce all key, new concepts and warnings, remarks and hints, from a practitioner’s perspective, wherever appropriate. Considerable background information and practical tips, from designing a PCB, to lay-out aspects, to trade-offs on system level, complement the discussion of basic principles, making this book a valuable reference for the experienced engineer.
