Part of the Wiley-Royal Microscopical Society Series, this book discusses the rapidly developing cutting-edge field of low-voltage microscopy, a field that has only recently emerged due to the rapid developments in the electron optics design and image processing.
It serves as a guide for current and new microscopists and materials scientists who are active in the field of nanotechnology, and presents applications in nanotechnology and research of surface-related phenomena, allowing researches to observe materials as never before.
List of Contributors ix Preface xi 1 Introduction to the Theory and
Advantages of Low Voltage Electron Microscopy 1 David C. Bell and Natasha
Erdman 1.1 Introduction 1 1.2 Historical Perspective 2 1.3 Beam
Interaction with Specimen Elastic and Inelastic Scattering 3 1.4
Instrument Configuration 11 1.5 Influence of Electron Optics Aberrations at
Low Voltages 12 1.6 SEM Imaging at Low Voltages 16 1.7 TEM/STEM Imaging and
Analysis at Low Voltages 26 1.8 Conclusion 27 References 28 2 SEM
Instrumentation Developments for Low kV Imaging and Microanalysis 31
Natasha Erdman and David C. Bell 2.1 Introduction 31 2.2 The Electron
Source 33 2.3 SEM Column Design Considerations 36 2.4 Beam Deceleration 41
2.5 Novel Detector Options and Energy Filters 43 2.6 Low Voltage STEM in SEM
48 2.7 Aberration Correction in SEM 50 2.8 Conclusions 53 References 53 3
Extreme High-Resolution (XHR) SEM Using a Beam Monochromator 57 Richard J.
Young, Gerard N.A. van Veen, Alexander Henstra and Lubomir Tuma 3.1
Introduction 57 3.2 Limitations in Low Voltage SEM Performance 58 3.3 Beam
Monochromator Design and Implementation 59 3.4 XHR Systems and Applications
63 3.5 Conclusions 69 Acknowledgements 70 References 70 4 The Application
of Low-Voltage SEM From Nanotechnology to Biological Research 73 Natasha
Erdman and David C. Bell 4.1 Introduction 73 4.2 Specimen Preparation
Considerations 74 4.3 Nanomaterials Applications 76 4.4 Beam Sensitive
Materials 84 4.5 Semiconductor Materials 85 4.6 Biological Specimens 87
4.7 Low-Voltage Microanalysis 91 4.8 Conclusions 92 References 93 5 Low
Voltage High-Resolution Transmission Electron Microscopy 97 David C. Bell
5.1 Introduction 97 5.2 So How Low is Low? 99 5.3 The Effect of Chromatic
Aberration and Chromatic Aberration Correction 100 5.4 The Electron
Monochromator 103 5.5 Theoretical Tradeoffs of Low kV Imaging 105 5.6 Our
Experience at 40 keV LV-HREM 109 5.7 Examples of LV-HREM Imaging 110 5.8
Conclusions 114 References 116 6 Gentle STEM of Single Atoms: Low keV
Imaging and Analysis at Ultimate Detection Limits 119 Ondrej L. Krivanek,
Wu Zhou, Matthew F. Chisholm, Juan Carlos Idrobo, Tracy C. Lovejoy, Quentin
M. Ramasse and Niklas Dellby 6.1 Introduction 119 6.2 Optimizing STEM
Resolution and Probe Current at Low Primary Energies 121 6.3 STEM Image
Formation 128 6.4 Gentle STEM Applications 135 6.5 Discussion 154 6.6
Conclusion 156 Acknowledgements 157 References 157 7 Low Voltage Scanning
Transmission Electron Microscopy of Oxide Interfaces 163 Robert Klie 7.1
Introduction 163 7.2 Methods and Instrumentation 166 7.3 Low Voltage
Imaging and Spectroscopy 168 7.4 Summary 180 Acknowledgements 180
References 180 8 What s Next? The Future Directions in Low Voltage
Electron Microscopy 185 David C. Bell and Natasha Erdman 8.1 Introduction
185 8.2 Unique Low Voltage SEM and TEM Instruments 186 8.3 Cameras,
Detectors, and Other Accessories 192 8.4 Conclusions 198 References 199
Index 201
