E-raamat: Design of Low-Voltage Bipolar Operational Amplifiers

,
Teised raamatud teemal:
  • Formaat - PDF+DRM
  • Hind: 159,93 €*
  • * hind on lõplik, st. muud allahindlused enam ei rakendu
  • Lisa ostukorvi
  • Lisa soovinimekirja
  • See e-raamat on mõeldud ainult isiklikuks kasutamiseks. E-raamatuid ei saa tagastada.
Design of Low-Voltage Bipolar Operational AmplifiersSuurem pilt
Teised raamatud teemal:

DRM piirangud

  • Kopeerimine (copy/paste):

    ei ole lubatud

  • Printimine:

    ei ole lubatud

  • Kasutamine:

    Digitaalõiguste kaitse (DRM)
    Kirjastus on väljastanud selle e-raamatu krüpteeritud kujul, mis tähendab, et selle lugemiseks peate installeerima spetsiaalse tarkvara. Samuti peate looma endale  Adobe ID Rohkem infot siin. E-raamatut saab lugeda 1 kasutaja ning alla laadida kuni 6'de seadmesse (kõik autoriseeritud sama Adobe ID-ga).

    Vajalik tarkvara
    Mobiilsetes seadmetes (telefon või tahvelarvuti) lugemiseks peate installeerima selle tasuta rakenduse: PocketBook Reader (iOS / Android)

    PC või Mac seadmes lugemiseks peate installima Adobe Digital Editionsi (Seeon tasuta rakendus spetsiaalselt e-raamatute lugemiseks. Seda ei tohi segamini ajada Adober Reader'iga, mis tõenäoliselt on juba teie arvutisse installeeritud )

    Seda e-raamatut ei saa lugeda Amazon Kindle's.

Design of Low-Voltage Bipolar Operational Amplifiers discusses the sub-circuits necessary to build a low-voltage operational amplifier. These include rail-to-rail input stages, rail-to-rail output stages, intermediate stages, protection circuitry and frequency compensation techniques. Of each of these, various implementations are examined. Furthermore, the book discusses realizations in silicon of the amplifiers.
The design and implementation of low-voltage bipolar Operational Amplifiers (OpAmps) is fully presented. A low supply voltage is necessary because the tendency towards chip components of smaller dimensions lowers the breakdown voltage of these components. Further, a low supply voltage is favorable because it enables operation of the OpAmp from just one single battery cell. The bipolar technology is chosen, because it is more suited for operation at low-voltages than the MOS technology.
The common-mode input voltage of the OpAmp must be able to have any value that fits within the supply voltage range. Input stages are discussed which are able to realize this at supply voltages down to 1.8 V, as well as down to 1 V.
The output voltage of the OpAmp must be able to have any value within the supply voltage range. One of the 1 V output stages that is discussed, the multi-path driven output stage, also has a high bandwidth with a high gain.
In addition to the input and output stage, the OpAmp comprises an intermediate stage, between the input stage and the output stage, to boost the overall gain of the OpAmp, and a class AB current control.
A frequency compensation technique is used to split apart the pole frequencies in the transfer function. A disadvantage of this nested Miller compensation, is that the resulting bandwidth is reduced by a factor of two. A new method, multi-path-driven Miller compensation, which does not have this drawback, is therefore introduced.
Several realizations are evaluated and a figure of merit is defined for the performance comparison of the OpAmps. One of the OpAmps operates at a 1 V supply, has a 3.4 MHz bandwidth with a 100 pF load and has a 700 &mgr;A supply current.
The book is an excellent reference for professional designers of amplifiers and may be used as a text for advanced courses on the subject.

Muu info

Springer Book Archives
1.1 Why Use a Low Supply Voltage?.- 1.2 Why Use Bipolar Technology?.- 1.3 Objectives of the Present Work.- 1.4 Design Considerations.- 1.5 Outline of This Book.- 1.6 References.- Input Stages.- 2.1 Complementary Input Stage.- 2.2 Complementary Input Stage with Constant Transconductance.- 2.3 Rail-To-Rail Input Stage at 1 Volt.- 2.4 Input Stage with Extended Input-Voltage Range.- 2.5 References.- Output Stages.- 3.1 Common-Emitter Output Stage.- 3.2 Darlington Output Stage.- 3.3 Widlar Output Stage.- 3.4 Multi-Path-Driven Output Stage.- 3.5 Parallel-Feedback Current Compensation.- 3.6 Conclusions.- 3.7 References.- Other Circuit Parts.- 4.1 Intermediate Stages.- 4.2 Class-AB Current Control-Circuits.- 4.2.1 Feedforward Class-AB Current Control.- 4.2.2 Feedback Class-AB Current Control.- 4.3 Output-Saturation Protection.- 4.4 Output-Current Limiters.- 4.5 Bias Circuit.- 4.6 Conclusions.- 4.7 References.- Frequency Compensation.- 5.1 Simple Miller Compensation.- 5.1.1 One-Pole Output Stage.- 5.1.2 Two-Pole Output Stage.- 5.2 Nested Miller Compensation.- 5.2.1 One-Pole Output Stage.- 5.2.2 Two-Pole Output Stage.- 5.3 Multi-Path-Driven Miller Compensation.- 5.4 Slewing.- 5.5 Conclusions.- 5.6 References.- Realizations.- 6.1 2-V Opamp NE5234.- 6.2 1-V Opamp IS549.- 6.3 Opamps U2010 and U2011.- 6.3.1 Darlington Output Stage.- 6.3.2 Widlar Output Stage.- 6.3.3 Multi-Path-Driven Output Stage.- 6.3.4 Parallel-Feedback-Current Compensated Output Stage.- 6.3.5 Common Circuit Parts.- 6.3.6 Measurement Results.- 6.4 1-V Opamp with 10-MHz Bandwidth.- 6.5 Conclusions.- 6.6 References.- Conclusions.- References.
