E-raamat: Introduction to Wireless Communication Circuits

, , , ,
  • Formaat: 468 pages
  • Ilmumisaeg: 01-Sep-2022
  • Kirjastus: River Publishers
  • Keel: eng
  • ISBN-13: 9781000795837
Teised raamatud teemal:
  • Formaat - PDF+DRM
  • Hind: 112,32 €*
  • * hind on lõplik, st. muud allahindlused enam ei rakendu
  • Lisa ostukorvi
  • Lisa soovinimekirja
  • See e-raamat on mõeldud ainult isiklikuks kasutamiseks. E-raamatuid ei saa tagastada.
Introduction to Wireless Communication CircuitsSuurem pilt
  • Formaat: 468 pages
  • Ilmumisaeg: 01-Sep-2022
  • Kirjastus: River Publishers
  • Keel: eng
  • ISBN-13: 9781000795837
Teised raamatud teemal:

DRM piirangud

  • Kopeerimine (copy/paste):

    ei ole lubatud

  • Printimine:

    ei ole lubatud

  • Kasutamine:

    Digitaalõiguste kaitse (DRM)
    Kirjastus on väljastanud selle e-raamatu krüpteeritud kujul, mis tähendab, et selle lugemiseks peate installeerima spetsiaalse tarkvara. Samuti peate looma endale  Adobe ID Rohkem infot siin. E-raamatut saab lugeda 1 kasutaja ning alla laadida kuni 6'de seadmesse (kõik autoriseeritud sama Adobe ID-ga).

    Vajalik tarkvara
    Mobiilsetes seadmetes (telefon või tahvelarvuti) lugemiseks peate installeerima selle tasuta rakenduse: PocketBook Reader (iOS / Android)

    PC või Mac seadmes lugemiseks peate installima Adobe Digital Editionsi (Seeon tasuta rakendus spetsiaalselt e-raamatute lugemiseks. Seda ei tohi segamini ajada Adober Reader'iga, mis tõenäoliselt on juba teie arvutisse installeeritud )

    Seda e-raamatut ei saa lugeda Amazon Kindle's.

This book is focused on special circuits dedicated to the RF level of wireless communications. From oscillators to modulation and demodulation and from mixers to RF and power amplifier circuits, the topics are presented in a sequential manner. A wealth of analysis is provided in the text alongside various worked out examples.

Over the past decade the tremendous development of wireless communications has changed human life incredibly. Considerable advancement has been made in the design and architecture of communications related RF and microwave circuits. This book is focused on special circuits dedicated to the RF level of wireless communications. From oscillators to modulation and demodulation and from mixers to RF and power amplifier circuits, the topics are presented in a sequential manner. A wealth of analysis is provided in the text alongside various worked out examples. Related problem sets are given at the end of each chapter. Basic concepts of RF analog circuit design are developedin the book.Technical topics discussed in the book include:
  • wireless communication systems
  • RF oscillators and phase locked loops
  • modulator and demodulator circuits
  • RF mixers
  • automatic gain control and limiters
  • microwave circuits, transmission lines and S-parameters
  • matching networks
  • linear amplifier design and power amplifiers
  • linearization techniques
