E-raamat: Low-Power Deep Sub-Micron CMOS Logic: Sub-threshold Current Reduction

  • Formaat - PDF+DRM
  • Hind: 55,56 €*
  • * hind on lõplik, st. muud allahindlused enam ei rakendu
  • Lisa ostukorvi
  • Lisa soovinimekirja
  • See e-raamat on mõeldud ainult isiklikuks kasutamiseks. E-raamatuid ei saa tagastada.

DRM piirangud

  • Kopeerimine (copy/paste):

    ei ole lubatud

  • Printimine:

    ei ole lubatud

  • Kasutamine:

    Digitaalõiguste kaitse (DRM)
    Kirjastus on väljastanud selle e-raamatu krüpteeritud kujul, mis tähendab, et selle lugemiseks peate installeerima spetsiaalse tarkvara. Samuti peate looma endale  Adobe ID Rohkem infot siin. E-raamatut saab lugeda 1 kasutaja ning alla laadida kuni 6'de seadmesse (kõik autoriseeritud sama Adobe ID-ga).

    Vajalik tarkvara
    Mobiilsetes seadmetes (telefon või tahvelarvuti) lugemiseks peate installeerima selle tasuta rakenduse: PocketBook Reader (iOS / Android)

    PC või Mac seadmes lugemiseks peate installima Adobe Digital Editionsi (Seeon tasuta rakendus spetsiaalselt e-raamatute lugemiseks. Seda ei tohi segamini ajada Adober Reader'iga, mis tõenäoliselt on juba teie arvutisse installeeritud )

    Seda e-raamatut ei saa lugeda Amazon Kindle's.

1. 1 Power-dissipation trends in CMOS circuits Shrinking device geometry, growing chip area and increased data-processing speed performance are technological trends in the integrated circuit industry to enlarge chip functionality. Already in 1965 Gordon Moore predicted that the total number of devices on a chip would double every year until the 1970s and every 24 months in the 1980s. This prediction is widely known as "Moore's Law" and eventually culminated in the Semiconductor Industry Association (SIA) technology road map [ 1]. The SIA road map has been a guide for the in­ dustry leading them to continued wafer and die size growth, increased transistor density and operating frequencies, and defect density reduction. To mention a few numbers; the die size increased 7% per year, the smallest feature sizes decreased 30% and the operating frequencies doubled every two years. As a consequence of these trends both the number of transistors and the power dissi­ pation per unit area increase. In the near future the maximum power dissipation per unit area will be reached. Down-scaling of the supply voltage is not only the most effective way to reduce power dissipation in general it also is a necessary precondition to ensure device reliability by reducing electrical fields and device temperature, to prevent device degradation. A draw-back of this solution is an increased signal propa­ gation delay, which results in a lower data-processing speed performance.

Muu info

Springer Book Archives
1. Introduction.- 1.1 Power-dissipation trends in CMOS circuits.- 1.2
Overview of present power-reduction solutions.- 1.3 Aim and scope of this
book.- 1.4 Organization of the book.-
2. Power Versus Energy.- 2.1 Power
considerations.- 2.2 Energy considerations.- 2.3 Conclusions.-
3. Power
Dissipation in Digital CMOS Circuits.- 3.1 Thermodynamics of computation.-
3.2 Functional power dissipation.- 3.3 Parasitical power dissipation.- 3.4
Trends in power dissipation.- 3.5 Conclusions.-
4. Reduction of Functional
Power Dissipation.- 4.1 Node transition-cycle activity factor.- 4.2 Clock
frequency.- 4.3 Transition-cycle energy.- 4.4 Conclusions.-
5. Reduction of
Parasitical Power Dissipation.- 5.1 Leakage power dissipation.- 5.2
Short-circuit power dissipation.- 5.3 Need for weak-inversion current
reduction.- 5.4 Conclusions.-
6. Weak-Inversion Current Reduction.- 6.1
Classification.- 6.2 Conclusions.-
7. Effectiveness of Weak-Inversion Current
Reduction.- 7.1 General effectiveness.- 7.2 Technique-specific
effectiveness.- 7.3 Conclusions.-
8. Triple-S Circuit Designs.- 8.1 Process
flow.- 8.2 Experimental circuits.- 8.3 Leakage, speed, area and functional
power.- 8.4 Practical applications and limitations.- 8.5 Conclusions.-
9.
Conclusions.-
10. Summary.- References.
