Nanostructured and Subwavelength Waveguides: Fundamentals and ApplicationsSuurem pilt
Teised raamatud teemal:

DRM piirangud

  • Kopeerimine (copy/paste):

    ei ole lubatud

  • Printimine:

    ei ole lubatud

  • Kasutamine:

    Digitaalõiguste kaitse (DRM)
    Kirjastus on väljastanud selle e-raamatu krüpteeritud kujul, mis tähendab, et selle lugemiseks peate installeerima spetsiaalse tarkvara. Samuti peate looma endale  Adobe ID Rohkem infot siin. E-raamatut saab lugeda 1 kasutaja ning alla laadida kuni 6'de seadmesse (kõik autoriseeritud sama Adobe ID-ga).

    Vajalik tarkvara
    Mobiilsetes seadmetes (telefon või tahvelarvuti) lugemiseks peate installeerima selle tasuta rakenduse: PocketBook Reader (iOS / Android)

    PC või Mac seadmes lugemiseks peate installima Adobe Digital Editionsi (Seeon tasuta rakendus spetsiaalselt e-raamatute lugemiseks. Seda ei tohi segamini ajada Adober Reader'iga, mis tõenäoliselt on juba teie arvutisse installeeritud )

    Seda e-raamatut ei saa lugeda Amazon Kindle's.

"This book presents semi-analytical theory and practical applications of a large number of subwavelength and nanostructured optical waveguides. The contents are organized around four major themes: guidance properties of subwavelength waveguides made of homogeneous anisotropic materials; description of guidance by nanostructured waveguides using effective media approximation; operation of nanostructured waveguides at shorter wavelength at the limit of validity of effective medium approximation; and practical applications of subwavelength and nanostructured waveguides.What makes the book unique is that it collects in a single place a large number of analytical solutions which are derived in a long wavelength regime for a plethora of practically important waveguides and fibers than researchers currently use or study worldwide. The waveguides considered include planar and circular isotropic and anisotropic waveguides, as well as surface waves on planar, and circular surfaces, and the waveguide materials include dielectrics, metals and polar materials. After analysis of the basic waveguide structures it considers waveguides made of the nanostructured materials. Many practical applications are then rigorouslydetailed including low-loss low-dispersion guidance using porous THz waves, long-range propagation of plasmons in thin metallic films, and leakage spectroscopy of leaky plasmonic modes propagating on thin metallic films.A companion website (password-protected) provides a fully functional transfer matrix code PolyTMat (Matlab) which is able to treat any multilayer waveguide of planar or circular geometry made of anisotropic dielectrics. "--



Optical waveguides take a prominent role in photonics because they are able to trap and to transport light efficiently between a point of excitation and a point of detection. Moreover, waveguides allow the management of many of the fundamental properties of light and allow highly controlled interaction with other optical systems. For this reason waveguides are ubiquitous in telecommunications, sensing, spectroscopy, light sources, and high power light delivery. Nanostructured and subwavelength waveguides have additional advantages; they are able to confine light at a length scale below the diffraction limit and enhance or suppress light-matter interaction, as well as manage fundamental properties of light such as speed and direction of energy and phase propagation.

This book presents semi-analytical theory and practical applications of a large number of subwavelength and nanostructured optical waveguides and fibers operating in various regions of the electromagnetic spectrum including visible, near and mid-IR and THz. A large number of approximate, while highly precise analytical expressions are derived that describe various modal properties of the planar and circular isotropic, anisotropic, and metamaterial waveguides and fibers, as well as surface waves propagating on planar, and circular interfaces. A variety of naturally occurring and artificial materials are also considered such as dielectrics, metals, polar materials, anisotropic all-dielectric and metal-dielectric metamaterials.

Contents are organized around four major themes:

  • Guidance properties of subwavelength waveguides and fibers made of homogeneous, generally anisotropic materials
  • Guidance properties of nanostructured waveguides and fibers using both exact geometry modelling and effective medium approximation
  • Development of the effective medium approximations for various 1D and 2D nanostructured materials and extension of these approximations to shorter wavelengths
  • Practical applications of subwavelength and nanostructured waveguides and fibers

Nanostructured Subwavelengths and Waveguides is unique in that it collects in a single place an extensive range of analytical solutions which are derived in various limits for many practically important and popular waveguide and fiber geometries and materials.
