E-raamat: Nuclear Systems Volume II: Elements of Thermal Hydraulic Design

(Massachusetts Institute of Technology, USA), (Massachusetts Institute of Technology, Cambridge, USA), (University of Maryland, USA)
  • Formaat: 657 pages
  • Ilmumisaeg: 13-Dec-2021
  • Kirjastus: CRC Press Inc
  • Keel: eng
  • ISBN-13: 9781482239614
  • Formaat - EPUB+DRM
  • Hind: 149,50 €*
  • * hind on lõplik, st. muud allahindlused enam ei rakendu
  • Lisa ostukorvi
  • Lisa soovinimekirja
  • See e-raamat on mõeldud ainult isiklikuks kasutamiseks. E-raamatuid ei saa tagastada.
  • Formaat: 657 pages
  • Ilmumisaeg: 13-Dec-2021
  • Kirjastus: CRC Press Inc
  • Keel: eng
  • ISBN-13: 9781482239614

DRM piirangud

  • Kopeerimine (copy/paste):

    ei ole lubatud

  • Printimine:

    ei ole lubatud

  • Kasutamine:

    Digitaalõiguste kaitse (DRM)
    Kirjastus on väljastanud selle e-raamatu krüpteeritud kujul, mis tähendab, et selle lugemiseks peate installeerima spetsiaalse tarkvara. Samuti peate looma endale  Adobe ID Rohkem infot siin. E-raamatut saab lugeda 1 kasutaja ning alla laadida kuni 6'de seadmesse (kõik autoriseeritud sama Adobe ID-ga).

    Vajalik tarkvara
    Mobiilsetes seadmetes (telefon või tahvelarvuti) lugemiseks peate installeerima selle tasuta rakenduse: PocketBook Reader (iOS / Android)

    PC või Mac seadmes lugemiseks peate installima Adobe Digital Editionsi (Seeon tasuta rakendus spetsiaalselt e-raamatute lugemiseks. Seda ei tohi segamini ajada Adober Reader'iga, mis tõenäoliselt on juba teie arvutisse installeeritud )

    Seda e-raamatut ei saa lugeda Amazon Kindle's.

This book provides advanced coverage of a wide variety of thermal fluid systems and technologies in nuclear power plants, including discussions of the latest reactor designs and their thermal/fluid technologies. Beyond the thermal hydraulic design and analysis of the core of a nuclear reactor, the book covers other components of nuclear power plants, such as the pressurizer, containment, and the entire primary coolant system.

Placing more emphasis on the appropriate models for small-scale resolution of the velocity and temperature fields through computational fluid mechanics, the book shows how this enhances the accuracy of predicted operating conditions in nuclear plants. It introduces considerations of the laws of scaling and uncertainty analysis, along with a wider coverage of the phenomena encountered during accidents.

FEATURES











Discusses fundamental ideas for various modeling approaches for the macro- and microscale flow conditions in reactors





Covers specific design considerations, such as natural convection and core reliability





Enables readers to better understand the importance of safety considerations in thermal engineering and analysis of modern nuclear plants





Features end-of-chapter problems





Includes a solutions manual for adopting instructors

This book serves as a textbook for advanced undergraduate and graduate students taking courses in nuclear engineering and studying thermal/hydraulic systems in nuclear power plants.
Preface xvii
Acknowledgments xix
Authors xxi
Chapter 1 Formulation of the Reactor Thermal Hydraulic Design Problem 1(18)
