E-raamat: Pulse and Synchro-Photon Electronics

This book presents the theory of large-signal nonlinear impulse processes occurring in bipolar and field-effect transistors with a Schottky gate, collapse TRAPATT and tunnel diodes, superlattices, and double heterojunction lasers. It evaluates the maximum speed of impulse operation of these elements and experimentally constructs the generation of pulse oscillations with a repetition frequency of up to 1, 2 and 4 GHz. Original or adapted methods of mathematical modeling of processes provide an opportunity to obtain quantitative dependencies of generated pulse parameters, while the book also details the synchro-photon effect. In addition, as shown here, when a semiconductor element is switched on by an electric pulse, and at the same time a pulse of photons synchronously illuminates it, an effect occurs which increases the switching speed of the element by an order of magnitude. At the same time, the switching transient characteristic is shortened by 10 times or more. After applying this effect in pulse generators in the gigahertz frequency range, an increase in the repetition frequency of the generated oscillations is possible.
