E-raamat: Guided Wave Photonics: Fundamentals and Applications with MATLAB

5.00/5 (4 hinnangut Goodreads-ist)
(Huawei Technologies Co., Ltd., European Research Center, Munich, Germany)
  • Formaat: 804 pages
  • Ilmumisaeg: 19-Apr-2016
  • Kirjastus: CRC Press Inc
  • ISBN-13: 9781439897164
Teised raamatud teemal:
  • Formaat - PDF+DRM
  • Hind: 84,50 €*
  • * hind on lõplik, st. muud allahindlused enam ei rakendu
  • Lisa ostukorvi
  • Lisa soovinimekirja
  • See e-raamat on mõeldud ainult isiklikuks kasutamiseks. E-raamatuid ei saa tagastada.
Guided Wave Photonics: Fundamentals and Applications with MATLABSuurem pilt
  • Formaat: 804 pages
  • Ilmumisaeg: 19-Apr-2016
  • Kirjastus: CRC Press Inc
  • ISBN-13: 9781439897164
Teised raamatud teemal:

DRM piirangud

  • Kopeerimine (copy/paste):

    ei ole lubatud

  • Printimine:

    ei ole lubatud

  • Kasutamine:

    Digitaalõiguste kaitse (DRM)
    Kirjastus on väljastanud selle e-raamatu krüpteeritud kujul, mis tähendab, et selle lugemiseks peate installeerima spetsiaalse tarkvara. Samuti peate looma endale  Adobe ID Rohkem infot siin. E-raamatut saab lugeda 1 kasutaja ning alla laadida kuni 6'de seadmesse (kõik autoriseeritud sama Adobe ID-ga).

    Vajalik tarkvara
    Mobiilsetes seadmetes (telefon või tahvelarvuti) lugemiseks peate installeerima selle tasuta rakenduse: PocketBook Reader (iOS / Android)

    PC või Mac seadmes lugemiseks peate installima Adobe Digital Editionsi (Seeon tasuta rakendus spetsiaalselt e-raamatute lugemiseks. Seda ei tohi segamini ajada Adober Reader'iga, mis tõenäoliselt on juba teie arvutisse installeeritud )

    Seda e-raamatut ei saa lugeda Amazon Kindle's.

Technical director of the European laboratory of a Chinese technology company, Binh investigates 100G and beyond optical transmission, and integrated optical technology and digital signal processing for extremely high transmission bit rates. Here he presents the theory and simulation of optical waveguides and wave propagation in a guided environment. His unified treatment covers the formulation of wave equations in the transverse plane and time-dependent propagation directions, the coupling of the guided wave systems, and nonlinear behaviors of the guided waves in such wave guiding systems. He assumes readers have a background in the propagation of electromagnetic waves, so dispenses with the usual introductory chapters on the fundamentals of the theory of guided waves, but does append the essentials. Annotation ©2011 Book News, Inc., Portland, OR (booknews.com)

A comprehensive presentation of the theory and simulation of optical waveguides and wave propagations in a guided environment, Guided Wave Photonics: Fundamentals and Applications with MATLAB® supplies fundamental and advanced understanding of integrated optical devices that are currently employed in modern optical fiber communications systems and photonic signal processing systems. While there are many texts available in this area, none provide the breadth and depth of coverage and computational rigor found in this one.

The author has distilled the information into a very practical, usable format. In a logical progression of theory and application, he starts with Maxwell's equations and progresses directly to optical waveguides (integrated optic and fiber optic), couplers, modulators, nonlinear effects and interactions, and system applications. With up-to-date coverage of applicable algorithms, design guides, material systems, and the latest device and system applications, the book addresses:

  • Fundamentals of guiding optical waves, including theoretical and simplified techniques
  • Linear and nonlinear aspects of optical waveguiding
  • Manipulating lightwaves by coupling and splitting
  • Interactions of lightwaves and ultra-fast electrical travelling waves in modern optical modulators
  • Applications of guided wave devices in optical communication systems and optical signal processing

Providing fundamental understanding of lightwave guiding and manipulating techniques, the text covers the field of integrated photonics by giving the principles, theoretical and applications. It explains how to solve the optical modes and their coupling as well as how to manipulate lightwaves for applications in communications and signal processing.
